Instruction set summary (continued) – Rainbow Electronics AT90S1200 User Manual
Page 64
64
AT90S1200
0838H–AVR–03/02
BIT AND BIT-TEST INSTRUCTIONS
SBI
P, b
Set Bit in I/O Register
I/O(P,b)
←
1
None
2
CBI
P, b
Clear Bit in I/O Register
I/O(P,b)
←
0
None
2
LSL
Rd
Logical Shift Left
Rd(n+1)
←
Rd(n), Rd(0)
←
0
Z,C,N,V
1
LSR
Rd
Logical Shift Right
Rd(n)
←
Rd(n+1), Rd(7)
←
0
Z,C,N,V
1
ROL
Rd
Rotate Left through Carry
Rd(0)
←
C,Rd(n+1)
←
Rd(n),C
←
Rd(7)
Z,C,N,V
1
ROR
Rd
Rotate Right through Carry
Rd(7)
←
C,Rd(n)
←
Rd(n+1),C
←
Rd(0)
Z,C,N,V
1
ASR
Rd
Arithmetic Shift Right
Rd(n)
←
Rd(n+1), n = 0..6
Z,C,N,V
1
SWAP
Rd
Swap Nibbles
Rd(3..0)
←
Rd(7..4),Rd(7..4)
←
Rd(3..0)
None
1
BSET
s
Flag Set
SREG(s)
←
1
SREG(s)
1
BCLR
s
Flag Clear
SREG(s)
←
0
SREG(s)
1
BST
Rr, b
Bit Store from Register to T
T
←
Rr(b)
T
1
BLD
Rd, b
Bit Load from T to Register
Rd(b)
←
T
None
1
SEC
Set Carry
C
←
1
C
1
CLC
Clear Carry
C
←
0
C
1
SEN
Set Negative Flag
N
←
1
N
1
CLN
Clear Negative Flag
N
←
0
N
1
SEZ
Set Zero Flag
Z
←
1
Z
1
CLZ
Clear Zero Flag
Z
←
0
Z
1
SEI
Global Interrupt Enable
I
←
1
I
1
CLI
Global Interrupt Disable
I
←
0
I
1
SES
Set Signed Test Flag
S
←
1
S
1
CLS
Clear Signed Test Flag
S
←
0
S
1
SEV
Set Two’s Complement Overflow
V
←
1
V
1
CLV
Clear Two’s Complement Overflow
V
←
0
V
1
SET
Set T in SREG
T
←
1
T
1
CLT
Clear T in SREG
T
←
0
T
1
SEH
Set Half-carry Flag in SREG
H
←
1
H
1
CLH
Clear Half-carry Flag in SREG
H
←
0
H
1
NOP
No Operation
None
1
SLEEP
Sleep
(see specific descr. for Sleep function)
None
1
WDR
Watchdog Reset
(see specific descr. for WDR/timer)
None
1
Instruction Set Summary (Continued)
Mnemonic
Operands
Description
Operation
Flags
# Clocks
