49
AT90S1200
0838H–AVR–03/02
Notes: 1. “Max” means the highest value where the pin is guaranteed to be read as low.
2. “Min” means the lowest value where the pin is guaranteed to be read as high.
3. Although each I/O port can sink more than the test conditions (20 mA at V
CC
= 5V, 10 mA at V
CC
= 3V) under steady state
conditions (non-transient), the following must be observed:
1] The sum of all I
OL
, for all ports, should not exceed 200 mA.
2] The sum of all I
OL
, for port D0 - D5 and XTAL2, should not exceed 100 mA.
3] The sum of all I
OL
, for ports B0 - B7 and D6, should not exceed 100 mA.
If I
OL
exceeds the test condition, V
OL
may exceed the related specification. Pins are not guaranteed to sink current greater
than the listed test condition.
4. Although each I/O port can source more than the test conditions (3 mA at V
CC
= 5V, 1.5 mA at V
CC
= 3V) under steady state
conditions (non-transient), the following must be observed:
1] The sum of all I
OH
, for all ports, should not exceed 200 mA.
2] The sum of all I
OH
, for port D0 - D5 and XTAL2, should not exceed 100 mA.
3] The sum of all I
OH
, for ports B0 - B7 and D6, should not exceed 100 mA.
If I
OH
exceeds the test condition, V
OH
may exceed the related specification. Pins are not guaranteed to source current
greater than the listed test condition.
5. Minimum V
CC
for power-down is 2V.
V
ACIO
Analog Comparator
Input Offset Voltage V
CC
= 5V
V
in
= V
CC
/ 2
40.0 mV
I
ACLK
Analog Comparator
Input Leakage Current V
CC
= 5V
V
in
= V
CC
/ 2
-50.0 50.0 nA
t
ACPD
Analog Comparator
Propagation Delay V
CC
= 2.7V
V
CC
= 4.0V
750.0
500.0 ns
DC Characteristics
T
A
= -40×C to 85×C, V
CC
= 2.7V to 6.0V (unless otherwise noted) (Continued)
Symbol Parameter Condition Min Typ Max Units
