RF Specification: VDD=1.8V Temperature=+20℃
Transmitter Performance
Parameter Min. Type Max. Bluetooth Spec. Unit
RF transmit power - 17 - 0 to +20 dBm
RF power control range - 20 - ≥16
RF power range control resolution - 0.5 -
20dB bandwidth for modulated carrier - 720 - ≤1000 KHz
Initial carrier frequency tolerance - 2.0 - ±75 KHz
Drift Rate - 8.0 - ±20 KHz/50uS
DH1 - 8.0 - ±24 KHz
DH3 - 9.0 - ±40 KHz
Carrier frequency
drift
DH5 - 10 - ±40 KHz
+/- 2 MHz - -40 - ≤- 20 dBm
+/- 3 MHz - -47 - ≤- 40 dBm
Adjacent
characteristic
+/- 4MHz - -50 - ≤- 40 dBm
△F1avg - 166 - 140≤△F1avg≤175 KHz
△F2avg - 157 - 115 KHz
Modulation
characteristic
△F1avg/△F1avg - 0.97 - ≥0.8
Receiver Performance
Parameter Frequency
（GHz）
Min. Type Max. Bluetooth Spec. Unit
2402 - -88 - dBm
2441 - -88 - dBm
Sensitivity at 0.1%
BER for all packet
types 2480 - -88 -
≤- 70
dBm
Maximum receive signal at 0.1% BER - -10 - ≥- 20 dBm
C/I co-channel - 9 - ≤11 dB
F=F
0
+1MHz - -3 - ≤0 dB
F=F
0
-1MHz - -7 - ≤0 dB
F=F
0
+2MHz - -41 - ≤- 30 dB
F=F
0
-2MHz - -42 - ≤- 20 dB
F=F
0
+3MHz - -43 - ≤- 40 dB
F=F
0
-5MHz - -42 - ≤- 40 dB
C/I performance
Adjacent channel
sensitivity
F=F
- -22 - ≤- 9 dB
Max. level of intermodulation
interferers
- -27 - ≥- 39 dBm
Spurious output level - -142 - dBm/Hz
