84

AT90S2313

0839I–AVR–06/02

Notes:

1. For compatibility with future devices, reserved bits should be written to zero if accessed. Reserved I/O memory addresses

should never be written.

2. Some of the Status Flags are cleared by writing a logical “1” to them. Note that the CBI and SBI instructions will operate on

all bits in the I/O Register, writing a “1” back into any flag read as set, thus clearing the flag. The CBI and SBI instructions
work with registers $00 to $1F only.

Register Summary

Address

Name

Bit 7

Bit 6

Bit 5

Bit 4

Bit 3

Bit 2

Bit 1

Bit 0

Page

$3F ($5F)

SREG

I

T

H

S

V

N

Z

C

page 16

$3E ($5E)

Reserved

$3D ($5D)

SPL

SP7

SP6

SP5

SP4

SP3

SP2

SP1

SP0

page 17

$3C ($5C)

Reserved

$3B ($5B)

GIMSK

INT1

INT0

page 22

$3A ($5A)

GIFR

INTF1

INTF0

page 23

$39 ($59)

TIMSK

TOIE1

OCIE1A

TICIE1

TOIE0

page 23

$38 ($58)

TIFR

TOV1

OCF1A

ICF1

TOV0

page 24

$37 ($57)

Reserved

$36 ($56)

Reserved

$35 ($55)

MCUCR

SE

SM

ISC11

ISC10

ISC01

ISC00

page 25

$34 ($54)

Reserved

$33 ($53)

TCCR0

CS02

CS01

CS00

page 29

$32 ($52)

TCNT0

Timer/Counter0 (8 Bits)

page 29

$31 ($51)

Reserved

$30 ($50)

Reserved

$2F ($4F)

TCCR1A

COM1A1

COM1A0

PWM11

PWM10

page 31

$2E ($4E)

TCCR1B

ICNC1

ICES1

.

CTC1

CS12

CS11

CS10

page 32

$2D ($4D)

TCNT1H

Timer/Counter1 – Counter Register High Byte

page 33

$2C ($4C)

TCNT1L

Timer/Counter1 – Counter Register Low Byte

page 33

$2B ($4B)

OCR1AH

Timer/Counter1 – Compare Register High Byte

page 34

$2A ($4A)

OCR1AL

Timer/Counter1 – Compare Register Low Byte

page 34

$29 ($49)

Reserved

$28 ($48)

Reserved

$27 ($47)

Reserved

$26 ($46)

Reserved

$25 ($45)

ICR1H

Timer/Counter1 – Input Capture Register High Byte

page 34

$24 ($44)

ICR1L

Timer/Counter1 – Input Capture Register Low Byte

page 34

$23 ($43)

Reserved

$22 ($42)

Reserved

$21 ($41)

WDTCR

WDTOE

WDE

WDP2

WDP1

WDP0

page 37

$20 ($40)

Reserved

$1F ($3F)

Reserved

$1E ($3E)

EEAR

EEPROM Address Register

page 39

$1D ($3D)

EEDR

EEPROM Data Register

page 39

$1C ($3C)

EECR

EEMWE

EEWE

EERE

page 40

$1B ($3B)

Reserved

$1A ($3A)

Reserved

$19 ($39)

Reserved

$18 ($38)

PORTB

PORTB7

PORTB6

PORTB5

PORTB4

PORTB3

PORTB2

PORTB1

PORTB0

page 50

$17 ($37)

DDRB

DDB7

DDB6

DDB5

DDB4

DDB3

DDB2

DDB1

DDB0

page 50

$16 ($36)

PINB

PINB7

PINB6

PINB5

PINB4

PINB3

PINB2

PINB1

PINB0

page 50

$15 ($35)

Reserved

$14 ($34)

Reserved

$13 ($33)

Reserved

$12 ($32)

PORTD

PORTD6

PORTD5

PORTD4

PORTD3

PORTD2

PORTD1

PORTD0

page 56

$11 ($31)

DDRD

DDD6

DDD5

DDD4

DDD3

DDD2

DDD1

DDD0

page 56

$10 ($30)

PIND

PIND6

PIND5

PIND4

PIND3

PIND2

PIND1

PIND0

page 56

...

Reserved

$0C ($2C)

UDR

UART I/O Data Register

page 45

$0B ($2B)

USR

RXC

TXC

UDRE

FE

OR

page 45

$0A ($2A)

UCR

RXCIE

TXCIE

UDRIE

RXEN

TXEN

CHR9

RXB8

TXB8

page 46

$09 ($29)

UBRR

UART Baud Rate Register

page 48

$08 ($28)

ACSR

ACD

ACO

ACI

ACIE

ACIC

ACIS1

ACIS0

page 48

Reserved

$00 ($20)

Reserved
