76
AT90S2313
0839I–AVR–06/02
Figure 60. Idle Supply Current vs. V
CC
Figure 61. Power-down Supply Current vs. V
CC
IDLE SUPPLY CURRENT vs. V
cc
I cc
(mA)
V
cc
(V)
FREQUENCY = 4 MHz
0
0.5
1
1.5
2
2.5
3
3.5
2 2.5 3 3.5 4 4.5 5 5.5 6
T = 25 ˚ C
A
T = 85 ˚ C
A
0
0.2
0.4
0.6
0.8
1
1.2
1.4
1.6
1.8
2
2 2.5 3 3.5 4 4.5 5 5.5 6
T = 85 ˚ C
A
T = 25 ˚ C
A
POWER DOWN SUPPLY CURRENT vs. V
cc
I cc
(µΑ)
V
cc
(V)
WATCHDOG TIMER DISABLED
T = 45 ˚ C
A
T = 70 ˚ C
A
