12-Channel/8-Channel, Flash-Configurable System
Managers with Nonvolatile Fault Registers
MAX16065/MAX16066
______________________________________________________________________________________ 57
Register Map (continued)
FLASH
ADDRESS
REGISTER
ADDRESS
READ/
WRITE
DESCRIPTION
278
078
R/W
Sequence delay for Slot 2 and Slot 3
279
079
R/W
Sequence delay for Slot 4 and Slot 5
27A
07A
R/W
Sequence delay for Slot 6 and Slot 7
27B
07B
R/W
Sequence delay for Slot 8 and Slot 9
27C
07C
R/W
Sequence delay for Slot 10 and Slot 11
27D
07D
R/W
Primary sequence final slot, sequence delay for Slot 12
MISCELLANEOUS
27E
07E
R/W
MON1/MON2 slot assignment
27F
07F
R/W
MON3/MON4 slot assignment
280
080
R/W
MON5/MON6 slot assignment
281
081
R/W
MON7/MON8 slot assignment
282
082
R/W
MON9/MON10 slot assignment
283
083
R/W
MON11/MON12 slot assignment
284
084
R/W
EN_OUT1/EN_OUT2 slot assignment
285
085
R/W
EN_OUT3/EN_OUT4 slot assignment
286
086
R/W
EN_OUT5/EN_OUT6 slot assignment
287
087
R/W
EN_OUT7/EN_OUT8 slot assignment
288
088
R/W
EN_OUT9/EN_OUT10 slot assignment
289
089
R/W
EN_OUT11/EN_OUT12 slot assignment
28A
08A
R/W
Customer use (version)
28B
08B
R/W
PEC enable/SMBus address
28C
08C
R/W
Lock bits
28D
08D
R
Revision code
NONVOLATILE FAULT LOG
200
—
R/W
Sequence state
201
—
R/W
Fault flags, MON1–MON8
202
—
R/W
Fault flags, MON9–MON12, OC, EXTFAULT
203
—
R/W
MON1 ADC output
204
—
R/W
MON2 ADC output
205
—
R/W
MON3 ADC output
206
—
R/W
MON4 ADC output
207
—
R/W
MON5 ADC output
208
—
R/W
MON6 ADC output
209
—
R/W
MON7 ADC output
20A
—
R/W
MON8 ADC output
20B
—
R/W
MON9 ADC output
20C
—
R/W
MON10 ADC output
20D
—
R/W
MON11ADC output
20E
—
R/W
MON12 ADC output
20F
—
R/W
Current-sense ADC output
