12-Channel/8-Channel, Flash-Configurable System
Managers with Nonvolatile Fault Registers
MAX16065/MAX16066
______________________________________________________________________________________ 23
Table
12. GPIO_ Configuration Registers (continued)
Table
13. GPIO_ Function Configuration Bits
REGISTER
ADDRESS
FLASH
ADDRESS
BIT RANGE
DESCRIPTION
41h
241h
[1:0]
GPIO6 configuration (MSB)
[4:2]
GPIO7 configuration
[7:5]
GPIO8 configuration
42h
242h
[0]
Output Configuration for GPIO1:
0 = Push-pull
1 = Open drain
[1]
Output Configuration for GPIO2:
0 = Push-pull
1 = Open drain
[2]
Output Configuration for GPIO3:
0 = Push-pull
1 = Open drain
[3]
Output Configuration for GPIO4:
0 = Push-pull
1 = Open drain
[4]
Output Configuration for GPIO5:
0 = Push-pull
1 = Open drain
[5]
Output Configuration for GPIO6:
0 = Push-pull
1 = Open drain
[6]
Output Configuration for GPIO7:
0 = Push-pull
1 = Open drain
[7]
Output Configuration for GPIO8:
0 = Push-pull
1 = Open drain
GPIO1
GPIO2
GPIO3
GPIO4
GPIO5
GPIO6
GPIO7
GPIO8
000
Logic input
Logic
input
Logic input
Logic input
Logic input
Logic
input
Logic input
Logic input
001
Logic output
Logic
output
Logic output
Logic output
Logic output
Logic
output
Logic output
Logic
output
010
Fault2 output
Fault2
output
Fault2 output
Fault2 output
Fault2 output
Fault2
output
Fault2 output
Fault2
output
011
Fault1 output
Fault1
output
FAULTPU
output
Fault1 output
Fault1 output
Fault1
output
Fault1 output
FAULTP
output
100
ANY_FAULT
output
RESET2
output
ANY_FAULT
output
ANY_FAULT
output
ANY_FAULT
output
RESET2
output
ANY_FAULT
output
RESET2
output
101
OVERC
output
OVERC
output
OVERC
output
OVERC
output
OVERC
output
OVERC
output
OVERC
output
OVERC
output
110
MR input
WDO
output
MR input
WDO output
MR input
WDO
output
MR input
WDO output
111
WDI input
—
—
EXTFAULT
input/output
EN2 input
MARGIN
input
EN2 input
EXTFAULT
input/output
