12-Channel/8-Channel, Flash-Configurable System
Managers with Nonvolatile Fault Registers
MAX16065/MAX16066
______________________________________________________________________________________ 31
Table
19. Nonvolatile Fault Log Registers (continued)
Table
20. Autoretry Configuration
FLASH ADDRESS
BIT RANGE
DESCRIPTION
202h
[0]
Fault log triggered on MON9
[1]
Fault log triggered on MON10
[2]
Fault log triggered on MON11
[3]
Fault log triggered on MON12
[4]
Fault log triggered on overcurrent
[5]
Fault log triggered on EXTFAULT
[7:6]
Not used
203h
[7:0]
MON1 ADC output bits 9–2
204h
[7:0]
MON2 ADC output bits 9–2
205h
[7:0]
MON3 ADC output bits 9–2
206h
[7:0]
MON4 ADC output bits 9–2
207h
[7:0]
MON5 ADC output bits 9–2
208h
[7:0]
MON6 ADC output bits 9–2
209h
[7:0]
MON7 ADC output bits 9–2
20Ah
[7:0]
MON8 ADC output bits 9–2
20Bh
[7:0]
MON9 ADC output bits 9–2
20Ch
[7:0]
MON10 ADC output bits 9–2
20Dh
[7:0]
MON11 ADC output bits 9–2
20Eh
[7:0]
MON12 ADC output bits 9–2
20Fh
[7:0]
Current-sense ADC output bits 9–2
REGISTER
ADDRESS
FLASH
ADDRESS
BIT RANGE
DESCRIPTION
74h
274h
[2:0]
Retry Delay:
000 = 20ms
001 = 40ms
010 = 80ms
011 = 150ms
100 = 280ms
101 = 540ms
110 = 1s
111 = 2s
[4:3]
Autoretry/Latch Mode:
00 = Latch
01 = Retry 1 time
10 = Retry 3 times
11 = Always retry
