12-Channel/8-Channel, Flash-Configurable System
Managers with Nonvolatile Fault Registers
MAX16065/MAX16066
______________________________________________________________________________________ 33
Table 21. EN_OUT1–EN_OUT12 Configuration (continued)
REGISTER ADDRESS FLASH ADDRESS BIT RANGE DESCRIPTION
31h 231h
[1:0]
EN_OUT5 Configuration:
00 = Active-low, open drain
01 = Active-high, open drain
10 = Active-low, push-pull
11 = Active-high, push-pull
[3:2]
EN_OUT6 Configuration:
00 = Active-low, open drain
01 = Active-high, open drain
10 = Active-low, push-pull
11 = Active-high, push-pull
[5:4]
EN_OUT7 Configuration:
00 = Active-low, open drain
01 = Active-high, open drain
10 = Active-low, push-pull
11 = Active-high, push-pull
[7:6]
EN_OUT8 Configuration:
00 = Active-low, open drain
01 = Active-high, open drain
10 = Active-low, push-pull
11 = Active-high, push-pull
32h (MAX16065 Only) 232h
[1:0]
EN_OUT9 Configuration:
00 = Active-low, open drain
01 = Active-high, open drain
10 = Active-low, push-pull
11 = Active-high, push-pull
[3:2]
EN_OUT10 Configuration:
00 = Active-low, open drain
01 = Active-high, open drain
10 = Active-low, push-pull
11 = Active-high, push-pull
[5:4]
EN_OUT11 Configuration:
00 = Active-low, open drain
01 = Active-high, open drain
10 = Active-low, push-pull
11 = Active-high, push-pull
[7:6]
EN_OUT12 Configuration:
00 = Active-low, open drain
01 = Active-high, open drain
10 = Active-low, push-pull
11 = Active-high, push-pull
