Table
8. Overcurrent Primary Threshold and Current-Sense Control
Table 9
. ADC Configuration Registers
REGISTER
ADDRESS
FLASH
ADDRESS
BIT
RANGE
DESCRIPTION
47h
247h
[0]
1 = Current sense is enabled
0 = Current sense is disabled
[1]
1 = CSP full-scale range is 14V
0 = CSP full-scale range is 7V
[3:2]
Overcurrent Primary Threshold and Current-Sense Gain Setting:
00 = 200mV threshold, A
V
= 6V/V
01 = 100mV threshold, A
V
= 12V/V
10 = 50mV threshold, A
V
= 24V/V
11 = 25mV threshold, A
V
= 48V/V
73h
273h
[6:5]
Overcurrent Secondary Threshold Deglitch:
00 = No delay
01 = 4ms
10 = 15ms
11 = 60ms
REGISTER ADDRESS
FLASH
ADDRESS
BIT RANGE
DESCRIPTION
43h
243h
[1:0]
ADC1 Full-Scale Range:
00 = 5.6V
01 = 2.8V
10 = 1.4V
11 = Channel not converted
[3:2]
ADC2 Full-Scale Range:
00 = 5.6V
01 = 2.8V
10 = 1.4V
11 = Channel not converted
[5:4]
ADC3 Full-Scale Range:
00 = 5.6V
01 = 2.8V
10 = 1.4V
11 = Channel not converted
[7:6]
ADC4 Full-Scale Range:
00 = 5.6V
01 = 2.8V
10 = 1.4V
11 = Channel not converted
