MAX6964
17-Output LED Driver/GPO
with Intensity Control
______________________________________________________________________________________ 13
Table 6. Blink Phase 0 Registers
REGISTER DATA
REGISTER R/
W
ADDRESS
CODE
(hex)
D7 D6 D5 D4 D3 D2 D1 D0
Write outputs O7–O0 phase 0 0
Read back outputs O7–O0 phase 0 1
0x02 OP7 OP6 OP5 OP4 OP3 OP2 OP1 OP0
Write outputs O15–O8 phase 0 0
Read back outputs O15–O8 phase 0 1
0x03 OP15 OP14 OP13 OP12 OP11 OP10 OP9 OP8
Table 7. Blink Phase 1 Registers
REGISTER DATA
REGISTER R/ W
ADDRESS
CODE
(hex)
D7 D6 D5 D4 D3 D2 D1 D0
Write outputs O7–O0 phase 1 0
Read back outputs O7–O0 phase 1 1
0x0A OP7 OP6 OP5 OP4 OP3 OP2 OP1 OP0
Write outputs O15–O8 phase 1 0
Read back outputs O15–O8 phase 1 1
0x0B OP15 OP14 OP13 OP12 OP11 OP10 OP9 OP8
Table 8. PWM Application Scenarios
APPLICATION RECOMMENDED CONFIGURATION
All outputs static without PWM
Set the master and global intensity register 0x0E to any value from 0x00 to 0x0F.
The global intensity G bit in the configuration register is don't care.
The output intensity registers 0x10 through 0x17 are don't care.
A mix of static and PWM outputs, with PWM
outputs using different PWM settings
Set the master and global intensity register 0x0E to any value from 0x10 to 0xFF.
Clear global intensity G bit to zero in the configuration register to disable global
intensity control.
For the static outputs, set the output intensity value to 0xF.
For the PWM outputs, set the output intensity value in the range 0x0 to 0xE.
A mix of static and PWM outputs, with PWM
outputs all using the same PWM setting As above. Global intensity control cannot be used with a mix of static and PWM
outputs, so write the individual intensity registers with the same PWM value.
All outputs PWM using the same PWM
setting
Set the master and global intensity register 0x0E to any value from 0x10 to 0xFF.
Set global intensity G bit to 1 in the configuration register to enable global intensity
control.
The master and global intensity register 0x0E is the only intensity register used.
The output intensity registers 0x10 through 0x17 are don't care.
