The global-intensity data is received in an intermediate
register and is applied to the outputs at subframe 0 and
PWM clock 0.
The MAX6972/MAX6973 have one byte of configuration
data with 5 active bit settings as shown in Table 6. One
byte of data containing configuration bit settings is sent
twice. Data is updated immediately into the CALDAC
latches. See Table 10. The loaded configuration settings
take effect immediately.
Serial Interface
The MAX6972/MAX6973 feature a fully synchronous
and fully buffered serial interface that allows cascading
of multiple devices. The serial interface consists of
inputs (CLKI, DIN, and LOADI) and outputs (CLKO,
DOUT, and LOADO). The MAX6972/MAX6973 can
pass different data to each cascaded device without
any additional inputs to identify the position of the
devices in the cascaded chain.
MAX6972/MAX6973
16-Output PWM LED Drivers
for Message Boards
______________________________________________________________________________________ 15
CONFIGURATION BIT ACRONYM FUNCTION DESCRIPTION
MSB D7 — 0 Not used
D6 — 0 Not used
D5 — 0 Not used
D4 GLB4 Global quarter
Enables the reduced global-intensity setting in the MAX6973 when set to
1. When set, the MAX6973 uses eight (or four, if multiplexing) PWM
subframes. GLB4 is set to 0 as power-on default. Setting bit D4 has no
effect in the MAX6972.
D3 PWM-ON
Enable
individual
PWMs
Turns all individual PWM outputs on when set to 1. Power-on default is
PWM-ON set to 0 to disable all current output drivers. PWM-ON can be
used to turn all LEDs on or off without affecting the global-intensity or
individual PWM settings.
D2 CRST
Reset frame
and PWM
counters
Setting CRST to 1 synchronously resets internal counters to 0. This action
sets the MAX6972/MAX6973 to subframe 0 of the global-intensity
subframe counter and clock 0 of all individual PWM counters. The CRST
bit is a nonlatching control function that resets to 0 after the counters are
set to 0.
D1 WDOG
Watchdog
enable
Setting WDOG to 1 enables the watchdog timer operation. Power-on
default is 0.
LSB D0 MUX
Multiplex
enable
Setting MUX to 1 turns multiplex mode on. Power-on default is 0.
Table 6. Load Configuration Bit Definitions
