MAX13481E/MAX13482E/MAX13483E
±15kV ESD-Protected USB Transceivers with
External/Internal Pullup Resistors
______________________________________________________________________________________ 17
Typical Operating Circuits
MAX13482E
SYSTEM
SUPPLY
VOLTAGE
V BUS V L
SYSTEM
INTERFACE
VM
VP
GND
D-
D+
GND
D-
D+
V PUR
V TRM
SUS
BD
ENUM
OE
PC
27 Ω ±1%
27 Ω ±1%
USB
POWER
0.1 μF
1 μF
1 μF
1.5k Ω
MAX13481E
SYSTEM
SUPPLY
VOLTAGE
V
BUS
VPU
V L
SYSTEM
INTERFACE
VM
VP
SP
GND
D-
D+
GND
D-
D+
V TRM
SUS
ENUM
OE
PC
27 Ω ±1%
27 Ω ±1%
USB
POWER
0.1 μF
1 μF
1 μF
