9081-OM (V4.6) 9081 PRODUCT MANUAL 3-9
Operating Instructions
9081 Function Submenu List and Descriptions
9081 Function Submenu List and Descriptions
Table 3-2 individually lists and describes each 9081 function submenu and its
related list selections, controls, and parameters. Where helpful, examples
showing usage of a function are also provided. Table 3-2 is primarily based
upon using DashBoard™ to access each function and its corresponding
submenus and parameters.
Note: All numeric (scalar) parameters displayed on DashBoard™ can be changed
using the slider controls,
arrows, or by numeric keypad entry in the corre-
sponding numeric field. (When using numeric keypad entry, add a return after
the entry to commit the entry.)
On DashBoard™ itself and in Table 3-2, the function submenu items are
organized using tabs as shown below.
The table below provides a quick-reference to the page numbers where each
function submenu item can be found.
Function Submenu Item Page Function Submenu Item Page
Audio Input Controls 3-10 Dolby Decoder (+DEC only) 3-28
Video Proc 3-11 Dolby E Metadata (+DEC only) 3-30
AFD 3-12 Dolby D Metadata (+DEC only) 3-31
Framesync 3-13 Tone Generator 3-37
Embedded Audio Group 1/2 3-18 Audio Mixing 3-32
Embedded Audio Group 3/4 3-22 Licensable Features 3-37
Timecode 3-24 Presets 3-38
