Cobalt Digital COMPASS 9081 HD_SD Frame Sync User Manual
Page 14

1
9081 Functional Description
1-10
9081 PRODUCT MANUAL
9081-OM (V4.6)
Loudness Processor (Option +LP)
Note:
Loudness processor function is an optional licensable feature. This function
and its controls appear only when a license key is entered and activated.
(This option (identified in Cobalt
®
price lists as +LP) can be purchased upon
initial order, or field-activated using a key string which is sent to you when this
option is purchased.)
If your card was purchased with option
+LP
, loudness processor manual
supplement “5.1 and Stereo Loudness Processing Options for Compass
®
Cards (+LP51, +LP20) Manual Supplement” (OPT-SW-LP-MS) is included
in your documentation package. Supplement OPT-SW-LP-MS can be
downloaded from our website or requested using the Cobalt contact
information in this manual.
2.0-to-5.1 Upmix Function
Note:
Upmix function is an optional licensable feature. This function and its controls
appear only when a license key is entered and activated. (This option (identi-
fied in Cobalt
®
price lists as +UM) can be purchased upon initial order, or
field-activated using a key string which is sent to you when this option is pur-
chased.)
The 2.0-to-5.1 upmixer function receives a normal PCM stereo pair from the
Audio Routing/Gain Control function and upmixes the pair to provide 5.1
channels (Left (
L
), Right (
R
), Center (
C
), Low Frequency Effects (
LFE
), Left
Surround (
Ls
), and Right Surround (
Rs
)). Whenever the upmixer is active, it
overwrites the six selected embedded channels with the new 5.1 upmix
signals (including replacing the original source stereo
L
and
R
inputs with
new
L
and
R
signals).
The 2.0-to-5.1 upmixer can be set to up mix in any of three modes: Always
upmix, Bypass upmix, or Auto enable/bypass upmixing. The Auto upmixing
mode looks at the signal levels on the selected channels and compares them to
a selectable level threshold. It then determines whether or not to generate 5.1
upmixing from the stereo pair as follows:
•
If the upmixer detects signal level below a selected threshold on all
four of the selected channels designated as
C
,
LFE
,
Ls
, and
Rs
, this
indicates to the upmixer that these channels are not carrying 5.1. In
this case, the upmixer overwrites all six selected channels with the
new 5.1 content.
•
If the upmixer detects signal level above a selected threshold on any
of the four selected channels designated as
C
,
LFE
,
Ls
, and
Rs
, this
indicates to the upmixer that the channel(s) are already carrying
viable 5.1 content. In this case, the upmixer is bypassed, allowing the
original channels to pass unaffected.
