Technical Specifications
1-16 9081 PRODUCT MANUAL 9081-OM (V4.6)
Audio and Video Formats Supported by the 9081
The 9081 supports all current SMPTE standard SD and HD video formats.
Table 1-1 lists and provides details regarding the audio and video formats
supported by the 9081.
Technical Specifications
Table 1-2 lists the technical specifications for the 9081 HD/SD Frame Sync
with Embedded Audio Processing and Dolby
® Decoding Option card.
Table 1-1 Supported Audio and Video Formats
Item Description/Specification
Input / Output Video Raster Structure: Frame Rate:
1080PsF 23.98; 24
1080p 23.98; 24
1080i
(1)
25; 29.97; 30
720p 23.98; 24; 25; 29.97; 30; 50; 59.94;
60
486i (1) 29.97
575i
(1)
25
Embedded Audio The 9081 supports all four groups (16 channels) of embedded audio at
full 24-bit resolution in both SD (with extended data packets) and HD.
(1) All rates displayed as frame rates; interlaced (“i”) field rates are two times the rate value shown.
Table 1-2 Technical Specifications
Item Characteristic
Part number, nomenclature • 9081 – HD/SD Frame Sync with Embedded Audio Processing
Installation/usage environment Intended for installation and usage in frame meeting openGear®
modular system definition.
Power consumption < 9 Watts maximum
Environmental:
Operating temperature:
Relative humidity (operating or storage): 32° – 104° F (0° – 40° C)
< 95%, non-condensing
Frame communication 10/100 Mbps Ethernet with Auto-MDIX.
