5-2 •••• Specifications 9211-OE, 9212-EO User Manual
9211-OE Technical Specifications
This section provides the technical specifications for the 9211-OE.
Table 5.1 9211-OE Technical Specifications
Category Parameter Specification
Number of Inputs 1
SMPTE Standards
Accommodated SMPTE 259M-C, SMPTE 292M, SMPTE
424M
Operating Wavelength Range 1210nm to 1600nm
Input Power Operating Range
(Color Bars) -3dBm to -18dBm @ 2.97Gbps
-3dBm to -19dBm @ 270Mbps and 1.5Gbps
Input Power Operating Range
(Pathological) -3dBm to -17dBm @ 2.97Gbps
-3dBm to -18dBm @ 270Mbps and 1.5Gbps
Receiver Overload At values above -3dB
Optical Input
Connector Type Single Mode, LC/UPC
Number of Outputs
Full Rear Module: 6
Split Rear Module: 3
SMPTE Standards
Accommodated SMPTE 259M-C, SMPTE 292M, SMPTE
424M
Impedance 75ohm
Return Loss
>15dB to 1.485GHz
>10dB from 1.485GHz to 2.97GHz
Signal Level 800mV ±10%
DC Offset 0Volts ±50mV
Rise and Fall Time (20-80%)
700ps. Typical (270Mbps)
120ps. Typical (1.485Gbps, 2.97Gbps)
Overshoot <10%
SDI Outputs
Connector Type BNC
Environmental Operating Range 0°C to 40°C
Power Power Consumption <4W
