2-8 •••• Installation and Setup 9211-OE, 9212-EO User Manual
Software Upgrades for the 9211-OE and 9212-EO
This section provides instructions for installing a license key and upgrading the software for your
9211-OE and 9212-EO using the DashBoard Control System™.
Use the following procedure to upload software to the 9211-OE and 9212-EO:
1. Contact Technical Support for the latest software version file.
2. In DashBoard, display the Device tab of the 9211-OE and 9212-EO by double-clicking its
status indicator in the Basic Tree View.
3. From the Device tab, click Upload to display the Select File for upload dialog box.
4. Navigate to the *.bin upload file you wish to upload. DashBoard automatically selects the
last directory that you loaded from.
5. Click Open to display a confirmation dialog box. This dialog box displays the selected
upload file name, type, size, and the file creation date.
6. From the Confirmation dialog box, select one of the following:
• Cancel — Select this option to cancel the upload of the file and return to the Device
View.
• Continue — Select this option to upload the file. While uploading, an Uploading
Progress dialog box opens.
Important — Pressing the Cancel button while uploading will leave the card in an invalid
state. Do not click Cancel unless the uploading progress has stopped completely for 60 seconds
or more. If upload fails, repeat the upload process from DashBoard. If the upload process fails
again, refer to the section “Bootload Button” on page 6-2.
7. Monitor the upgrade progress bar displayed in DashBoard while the software is upgraded
on your 9211-OE and 9212-EO.
8. To complete the upgrade process, you must reboot the card as follows:
• The reboot process takes up to 30 seconds.
Note — The communications processor of the 9211-OE and 9212-EO requires
approximately 30 seconds to re-start and re-establish network communications.
• The 9211-OE and 9212-EO automatically saves all your settings before starting the
reboot process.
• The reboot process is complete once the status indicators for the Card State and
Connection return to their previous status.
This completes the procedure to upload software to the 9211-OE and 9212-EO.
