9211-OE, 9212-EO User Manual Menus •••• 4-3
DashBoard Menus for the 9211-OE and 9212-EO
The DashBoard Control System™ enables you to monitor and control openGear frames and cards
from a computer. DashBoard communicates with other cards in a 20-slot frame through the
Network Controller Card. This section briefly summarizes the menus, items, and parameters
available from the DashBoard Control System™ for the 9211-OE and 9212-EO. Default values are
indicated with an asterisk (*).
Status Tab
Table 4.1 summarizes the Status tab parameters available in DashBoard. The Status tabs provide
read-only information such as software revision issue, hardware status, and power consumption.
Table 4.1. Status Menu Functions
Menu Item Parameters Description
Product
9211-OE or
9212-EO
Supplier Cobalt Digital Inc.
Board Rev ##
Board S/N ###### Indicates the card serial number
Product
(Read-
only)
Software Rev ##.## Indicates the software version
OK
FPGA load invalid
Incomp I/O Module
Current out of spec
Internal Error
SFP Temp Low
SFP Temp High
SFP Power High
SFP Power Low
SFP Tx Fault
HW Status
SFP Not Detected
Indicates the status of the hardware
including the SFP module. Some
messages displayed are dependent on
the settings in the Alarms Enable tab.
Voltage (mV) # Supply Voltage
Hardware
(Read-
only)
Current (mA) # Current consumption of card
