9083 Function Submenu List and Descriptions
9083 Function Submenu List and Descriptions
Table 3-2 individually lists and describes each 9083 function submenu (‘tab”)
and its related list selections, controls, and parameters. Where helpful,
examples showing usage of a function are also provided. Table 3-2 is
primarily based upon using DashBoard™ to access each function and its
corresponding submenus and parameters.
Note:
All numeric (scalar) parameters displayed on DashBoard™ can be changed
using the slider controls,
arrows, or by numeric keypad entry in the corre-
sponding numeric field. (When using numeric keypad entry, add a return after
the entry to commit the entry.)
On DashBoard™ itself and in Table 3-2, the function submenu items are
organized using tabs as shown below.
The table below provides a quick-reference to the page numbers where each
function submenu item can be found.
Function Submenu Item
Page
Function Submenu Item
Page
3-10
Dolby Decoder (9083-DEC only)
3-32
3-13
Dolby E Metadata (9083-DEC only)
3-35
3-14
Dolby D Metadata (9083-DEC only)
3-36
3-15
3-37
3-20
3-41
3-24
3-46
3-26
3-46
3-30
3-47
Dolby Metadata (9083 only)
3-31
