Audio and Video Formats Supported by the 9083
The 9083 supports all current SMPTE standard SD and HD video formats.
Table 1-1 lists and provides details regarding the audio and video formats
supported by the 9083.
Table 1-1
Supported Audio and Video Formats
Item
Description/Specification
Input / Output Video
Raster Structure:
Frame Rate:
1080PsF
23.98; 24
1080p
23.98; 24
1080i
(1)
25; 29.97; 30
720p
23.98; 24; 25; 29.97; 30; 50; 59.94; 60
486i
(1)
29.97
575i
(1)
25
Embedded Audio
The 9083 supports all four groups (16 channels) of embedded audio at
full 24-bit resolution in both SD (with extended data packets) and HD.
Analog Audio
The 9083 supports 8 channels of balanced (differential) analog audio.
The analog audio is encoded such that a +24 dBu input is equivalent to
digital 0 dBFS.
Discrete AES Audio Input
The 9083 can accept 16 channels (8 pairs) of discrete AES audio on
75
Ω
BNC connections. Sample rate conversion can be employed to
account for minor clock rate differences in the AES stream and the
input video stream.
Note: The AES signal must have a nominal rate of approximately
48 kHz. The 9083 does not support AES input at 32 kHz,
44.1 kHz, 96 kHz or 192 kHz rates.
Discrete AES Audio Output
The 9083 can provide 16 channels (8 pairs) of discrete AES audio on
75
Ω
BNC connections.
(9083-DEC only) Dolby
®
E/
Dolby
®
Digital™ Audio Input
Decode
The 9083-DEC provides up to 10 decoded AES channels when valid
Dolby
®
E or Dolby
®
Digital™ audio is received on either discrete AES
or embedded inputs with corresponding metadata.
(1) All rates displayed as frame rates; interlaced (“i”) field rates are two times the rate value shown.
