Peerless Lighting EGAW1 - T5_T5HO - Manual (Page 2)

PHOTOMETRICS
WEIGHTS & SUPPORT SPACING
CONFIGURATIONS
MOUNTING DETAIL
2246 5th Street, Berkeley, CA 94710 • Tel: 510.845.2760 • Fax: 510.845.2776 • Email: [email protected] • PeerlessLighting.com
4’–6 3 ⁄
4
” O.A.
6’–8”
8’–5” O.A.
5’–4” 5’–4”
12’–3 1 ⁄
2
” O.A.
1’–4” Typical
2’–8”
STANDARD SECTIONS Key:
Support location
•
Feed location
EM feed location
ELEVATION
3 ⁄
8
”
*Dimension shown is from mounting hole to top of luminaire
Center of switchbox
to top of fixture
Feed Cover Plate
#005 Soft White
Screw #10
Wall Bracket
2” x 4” switch box
at feed, mounted
horizontally —
by others
9 ⁄
16
”*
7 ⁄
8
”
Retainer Bracket
Type: ________________________
Project: ______________________
Angular sweep connectors for inside corners and mitered connectors for inside and outside corners available for wall
configurations. Reference Pattern Connector Guide for additional details.
Actual performance may differ as a result of end-user environment and application.
16 LBS
32 LBS
43 LBS
2
© 2012 Acuity Brands Lighting, Inc. All Rights Reserved. “Peerless” and “Lightedge” are registered trademarks of Acuity Brands Lighting.
Products in this document may be covered by one or more U.S. Patents and Patents Pending. Specifications subject to change without notice.
1-year limited warranty. Complete warranty terms located at www.acuitybrands.com/customerresources/terms_and_conditions.aspx Indirect T5/T5HO
EGAW1 Lightedge Angular Wall
1-LAMP T5HO
65.1% efficiency
3255 delivered lumens
100.0% up / 0.0% down
2-LAMP T5HO
60.3% efficiency
6027 delivered lumens
100.0% up / 0.0% down
Wall Mount EGAW1
Lightedge Angular Wall
Indirect T5/T5HO
