Peerless Lighting LL1W - T5_T5HO User Manual
Lightline wall, Indirect t5/t5ho, Wall mount
LAMPING OPTIONS
SPECIFICATIONS
CATALOG NUMBER
S P E C I F I C A T I O N S
2246 5th Street, Berkeley, CA 94710
•
Tel: 510.845.2760
•
Fax: 510.845.2776
•
•
__________ __________ __________ __________ __________ __________ __________ __________ __________ __________ __________ __________ __________ _____________________
4
3
/
4
”
1
1
/
4
”
2
1
/
4
”
6"
Type:
________________________
Project:
______________________
1
© 2012 Acuity Brands Lighting, Inc. All Rights Reserved. “Peerless” and “Lightline” are registered trademarks of Acuity Brands Lighting.
Products in this document may be covered by one or more U.S. Patents and Patents Pending. Specifications subject to change without notice.
1-year limited warranty. Complete warranty terms locat
Indirect T5/T5HO
LL1W1 Lightline Wall
Examples:
LL1W1 D 1 28T5 8FT R8 120 GEB10 SCT LP830 C100 — LL1W1 X 1 54T5HO 12FT R12 120 ADEZ SCT LP830 C041
Wall Mount
LL1W1
Lightline Wall
Indirect T5/T5HO
Construction
Housing is extruded aluminum forming a
2
3
⁄
4
”x 2
1
⁄
2
” rectangular profile. Die-cast end plate
mechanically attaches with no exposed fasteners.
Reflectors
Die-formed, pre-finished white reflector with
hammertone specular aluminum.
Electrical
Specify 120V, 277V or 347V. Pre-wired with 16AWG
fixture wires. For special circuiting or wire gauge,
consult factory. Plug-in electrical connectors
included. UL and C-UL listed.
Finish
Standard colors include satin anodized aluminum,
and white white (low gloss). Custom colors
available, consult factory.
Luminaire Length
4’, 8’, and 12’ lengths for a single section. For total
luminaire length, add
3
⁄
4
” for each end plate. Using
internal joiners, 4’, 8’, and 12’ sections can be joined
to form longer rows.
__________
__________
__________
__________
_________
__________
__________
__________
__________
Luminaire
LL1W1
Mounting Type
D
Wall spacer
X
6” extended
arm mount
# of Lamps in
Cross Section
1
Lamp Type
28T5
1
28W T5
54T5HO 54W T5HO
Luminaire
Row Length
X FT
(4’ increments)
Maximum
Section Length
R4
4’ section(s)
R8
8’ section(s)
R12
12’ section(s)
Voltage
120
277
347
Ballast Type
GEB10
<10% THD Electronic
ADEZ
1,2
Advance Mark 10 dim
DMHL3D
1
Lutron Hi-Lume dim
ADZT
1
Advance Mark 7 0-10V dim
OSDIM
1,2
Osram 0-10V dim
Referenc
ebsite
or consult factory for other options.
# of Emergency
Modules
(Blank) None
1SE
1 section
2SE
2 sections
XSE
X sections
______________
________________
________________
______________
_________________________________
Emergency Type
3
(Blank) None
EC
Emergency circuit
EL
1
Emergency battery pack
EN
1
Emergency battery pack
w/night light circuit
Switching
SCT
Single circuit
Lamp Color
L/LP No lamp
LP830 3000k 80+ CRI
LP835 3500k 80+ CRI
LP841 4100k 80+ CRI
Available with T5 only:
LP830P 3000K 80+ CRI Premier
LP835P 3500K 80+ CRI Premier
LP841P 4100K 80+ CRI Premier
Referenc
ebsite or
consult factory for other options.
Finish
C041 White white (low gloss)
C100 Satin anodized finish
C099 Custom finish
Options
DL
Damp location label
ELH
Emergency through wiring w/separate feed
ELS
Emergency through wiring w/single feed,
shared neutral
ELS2 Emergency through wiring w/single feed,
separate neutrals
GLR Fusing (fast blow)
GMF Fusing (slow blow)
Notes:
1 Not available in 347V
2 Not available with 28T5 lamps
3 Emergency type is installed in last 4’ of luminaire
sections. Separate feed required unless ELS or ELS2 is
specified
5
⁄
8
”
2
1
⁄
2
”
LL1W1 X
2
3
⁄
4
”
LL1W1 D
