PHOTOMETRICS
WEIGHTS & SUPPORT SPACING
CONFIGURATIONS
2246 5th Street, Berkeley, CA 94710 • Tel: 510.845.2760 • Fax: 510.845.2776 • Email: [email protected] • PeerlessLighting.com
INTEGRATED NLIGHT MICRO SENSOR
PLAN VIEW
STANDARD SECTIONS
4’-0 1 ⁄
4
” 9 ⁄
16
” end plate
4’-1 3 ⁄
8
” O.A.
8’-0 1 ⁄
8
”
8’-1 1 ⁄
4
” O.A.
12’-0”
12’-1 1 ⁄
8
” O.A.
Key:
• Support or feed location
Type: ________________________
Project: ______________________
24 LBS
43 LBS
62 LBS
Mitered corner, “T” and “X” connectors available for suspended configurations.
Reference Pattern Connector Guide for additional details.
Actual performance may differ as a result of end-user environment and application.
2
