PHOTOMETRICS
WEIGHTS & SUPPORT SPACING
CONFIGURATIONS
MOUNTING DETAIL
2246 5th Street, Berkeley, CA 94710
•
Tel: 510.845.2760
•
Fax: 510.845.2776
•
•
4’-2
3
⁄
4
” O.A.
12’-2
1
⁄
2
” O.A.
8’-2
5
⁄
8
” O.A.
1
1
⁄
4
” end cap
2’-8”
8
1
⁄
8
”
8
1
⁄
16
”
8”
6’-8”
5’-4”
5’-4”
PLAN VIEW
STANDARD SECTIONS
Key:
Support location
Standard feed location
•
EM feed location
2X4 Switch Box
(By others)
Wall Bracket
Mounting holes
for
1
⁄
4
” bolt
Mounting holes to fixture
4
7
⁄
16
”
Type:
________________________
Project:
______________________
Suspension spacing equals section length. Consult factory for stem mounting suspension spacing.
Actual performance may differ as a result of end-user environment and application.
12–13.5 LBS
24–25.5 LBS
36–37.5 LBS
Tenon inside, outside “L” and straight connectors available for suspended configurations.
Referenc
for additional details.
2
© 2012 Acuity Brands Lighting, Inc. All Rights Reserved. “Peerless” and “IceTray” are registered trademarks of Acuity Brands Lighting.
Products in this document may be covered by one or more U.S. Patents and Patents Pending. Specifications subject to change without notice.
1-year limited warranty. Complete warranty terms locat
Direct T8
IRDW8 IceTray Rectangular Wall Direct
1-LAMP T8 OPI
36.2% efficiency
1030 delivered lumens
51.0% up / 49.0% down
Wall Mount
IRDW8
IceTray Rectangular Wall Direct
Direct T8
