WEIGHTS & SUPPORT SPACING
STANDARD SECTIONS
4’-6 1 ⁄
4
” O.A.
3” for end cap
8’-6” O.A.
8’-0”
PLAN VIEW
Key:
• Support or feed location
8 1 ⁄
8
”
4 1 ⁄
4
”
8” 8”
Type: ________________________
Project: ______________________
2 RD4W1 Round 4 LED Wall Indirect
Suspension spacing equals section length.
Wall Mount — 4” Round RD4W1
Round 4
LED
Wall Indirect
18 LBS
34 LBS
PHOTOMETRICS
90
100
110
120
130
140
150 160 170
150
300
450
600
90
100
110
120
130
140
W20 LP835
59 lumens per watt
1170 delivered lumens
100% up
W40 LP835
54 lumens per watt
2185 delivered lumens
100% up
Actual performance may differ as a result of end-user environment and application.
LIGHTING FACTS LABELS
RD4W1 1170L 3500K RD4W1 2185L 3500K
