Mirage, Indirect-direct t5ho, Suspended – Peerless Lighting MRM4 - T5_T5HO User Manual
Page 2: Mrm4
PHOTOMETRICS
WEIGHTS & SUPPORT SPACING
CONFIGURATIONS
2246 5th Street, Berkeley, CA 94710
•
Tel: 510.845.2760
•
Fax: 510.845.2776
•
•
PLAN VIEW
Key:
•
Support or feed location
Default sensor location (if ordered)
Type:
________________________
Project:
______________________
26 LBS
40 LBS
51 LBS
4’-0
1
⁄
4
”
4-0
1
⁄
4
” Typical
4’-8
3
⁄
4
” O.A.
8’-0”
8’-8
1
⁄
2
” O.A.
12’-8
1
⁄
2
” O.A.
12’-0”
Suspension spacing equals section length.
Aluminum cast corners available.
Reference
or additional details.
Actual performance may differ as a result of end-user environment and application.
2
© 2012 Acuity Brands Lighting, Inc. All Rights Reserved. “Peerless” and “Mirage” are registered trademarks of Acuity Brands Lighting.
Products in this document may be covered by one or more U.S. Patents and Patents Pending. Specifications subject to change without notice.
1-year limited warranty. Complete warranty terms locat
Indirect-Direct T5HO
MRM4 Mirage
Suspended
MRM4
Mirage
Indirect-Direct T5HO
1-LAMP T5HO
92.6% efficiency
4632 delivered lumens
76.6% up / 23.4% down
2-LAMP T5HO
91.2% efficiency
9125 delivered lumens
83.2% up / 16.8% down
