Envision wall, Indirect t8, Wall mount – Peerless Lighting ENW1 - T8 User Manual
Page 2: Enw1
WEIGHTS & SUPPORT SPACING
CONFIGURATIONS
PHOTOMETRICS
MOUNTING DETAIL
2246 5th Street, Berkeley, CA 94710
•
Tel: 510.845.2760
•
Fax: 510.845.2776
•
•
STANDARD SECTIONS
Key:
Support location
Standard feed location
•
EM feed location
1’-4”
4’-0
1
/
2
” O.A.
2’-8”
1’-4”
8’-0
1
/
2
” O.A.
6’-8”
1’-4”
12’-0
1
/
2
” O.A.
5’-4”
5’-4”
1
/
4
” end plate
ELEVATION
Type:
________________________
Project:
______________________
Cast inside and outside corner connectors available for wall configurations.
Referenc
for additional details.
Actual performance may differ as a result of end-user environment and application.
24 LBS
48 LBS
72 LBS
Retainer Bracket
4”
2
1
⁄
2
”
1
⁄
4
”
Nut #10-24
1”
Top of fixture
mounting holes
2” x 4” switch box
at feed, mounted
horizontally—by others
Wall Bracket
Caution:
Wall must be adequately reinforced at support
locations for sound structural and aesthetic
installations of the luminaire — by others
2
© 2012 Acuity Brands Lighting, Inc. All Rights Reserved. “Peerless” and “Envision” are registered trademarks of Acuity Brands Lighting.
Products in this document may be covered by one or more U.S. Patents and Patents Pending. Specifications subject to change without notice.
1-year limited warranty. Complete warranty terms locat
Indirect T8
ENW1 Envision Wall
1-LAMP T8
62.4% efficiency
1811 delivered lumens
100.0% up / 0.0% down
2-LAMP T8
46.9% efficiency
2720 delivered lumens
100.0% up / 0.0% down
Wall Mount
ENW1
Envision Wall
Indirect T8
