C — Transducer
Female square drive.
D — Battery Access
Battery Pack housing panel. Remove Phillips screw
to access Battery Pack.
E — Power Switch
Rocker switch turns power to tester on and off.
F — Audible Alert
Signal sounds momentarily when:
• Power to tester is initiated,
• Target Torque is reached.
G — Swivel
Holds the display for view from any angle.
H — AC Adapter Jack
Receptacle (9VDC @ 1.66A max) for continuous AC
operation.
I — USB Jack
Receptacle for uploading torque data to external
computer.
7
DTT Digital Torque Tester
• Anytime a button pressed, and
