4. In the SELECT TEST TYPE screen, select either:
QUICK CHECK (used when verifying torque
wrench readings), or
AUDIT (used when testing a torque wrench)
5a. If QUICK CHECK is selected in Step 4, the tester will
display the TEST SETUP screen (Figure 6).
5b. Press the CHANGE button next to TGT TORQUE to
enter the Target Torque Value and Units desired
(Figure 7).
NOTE: If the incorrect value is entered, press BS to
clear the last digit entered, or press CLEAR to
delete the entire entry.
Press UNITS to scroll between FT-LB, IN-LB,
IN-OZ, KG-CM, Nm and cNm units.
Press NEXT to accept the entry and return to the
TEST SETUP screen.
13
DTT Digital Torque Tester
ENTER TARGET TORQUE VALUE :
MAIN CLEAR NEXT UNITS
Figure 7: Target Torque Value screen
FT-LB
250
1 2 3 4
5 6 7 8
9 0 BS
Quick Check
Mode
DIGITAL TORQUE TESTER
TEST SETUP
MAIN TEST
CHANGE
CHANGE
CHANGE
Figure 6: Test Setup screen (Quick Check mode)
TGT TORQUE : 250 FT-LB
SERIAL NUM : 110900MAW
OPERATOR ID : TECH512
