Tester Setup
1. Turn the power switch ON.
2. In the MAIN MENU screen, select DTT SETTINGS.
3. In the SYSTEM CONFIGURATION screen, the display
reads:
DATE: MONTH / DAY / YEAR
TIME: HOUR / MINS
BRIGHTNESS: 30-100
4. To increment or decrement the DATE/TIME/BRIGHTNESS
elements, select the element and repeatedly press the
UP or DOWN arrows.
NOTE: Press and hold the UP or DOWN arrows to
change the display quickly. The scrolling
DATE/TIME elements roll over at both ends for
quick and convenient adjustment of settings.
5. Press NEXT to update DATE/TIME/BRIGHTNESS and
return to the MAIN MENU.
11
DTT Digital Torque Tester
SYSTEM CONFIGURATION
SW VERSION: 1.X.X CHECKSUM: A1XX
DATE:
TIME: HR MIN
BRIGHTNESS:
Nov 03 2009
11 07
60
NEXT
Figure 4: System Configuration screen
