5e. Press the TEST button to accept all entries and
display the QUICK CHECK test screen (Figure 12).
NOTE: The operator can return to the TEST SETUP
screen by pressing the SETUP button.
5f. Install the wrench on the transducer and apply torque.
5g. Press STORE to save torque measurements in the
internal memory. Torque measurements can be
offloaded to a PC using the USB cable. For
additional information refer to Data Offload.
6a. If AUDIT is selected in Step 4, the tester will display
the TEST SETUP screen (Figure 13).
16
DTT Digital Torque Tester
0.0O
TGT TORQUE: 250
FIRST PEAK
FT-LB
MAIN MENU SETUP STORE
DATA: 25
Figure 12: Quick Check test screen
Audit Mode
DIGITAL TORQUE TESTER
TEST SETUP
MAIN TEST
CHANGE
CHANGE
CHANGE
Figure 13: Test Setup screen (Audit Mode)
WRENCH SIZE : 250 FT-LB
SERIAL NUM : 110900MAW
OPERATOR ID : TECH512
