I. Note: The above procedure only works because the servo is turned off. In this mode the
setpoint sets the output manually and ignores the motor amperage feedback signal, which
during the catch and weigh test is will be zero. The procedure works because you manu-
ally establish a flow rate with the wheel motor amps and then, without changing the man-
ual output setting, perform a catch and weigh test. In order to select another flow rate it will
be necessary to have the feed spout in place and, with the wheel running, manually set
the output to a new amperage condition.
14.
SPECIFICATIONS
15. WIRING CONNECTIONS
Power: 24 Vdc @ 0.5 Amp
Inputs: 0-5 A ac from current transformer loop
Remote analog setpoint 0-10 Vdc
Enable input 24 Vdc
Alarm reset 24 Vdc
Outputs: Servo output signal 0-10 Vdc
Recorder Analog output 0-10 Vdc
Alarm relay contacts (rated at 120 Vac @ 0.5 Amp)
Enable output signal 24 Vdc
Weight: 2.2 pounds / 1 Kg
Display range: 0-1999
Decimal Points: 1000, 100.0, 10.00
Alarm Band-
width:
0-50% of full scale or of set point
Alarm Delay: 0-10 seconds
Enable Delay: 0-10 seconds
1
0 Vdc, Common 0 Vdc, Common 11
2
Remote Setpoint (0-10 Vdc) Alarm Reset (24 Vdc)
12
3
0 Vdc, Common Alarm High Relay Contact
13
4
Enable Input (24 Vdc) Alarm Common Relay Contact
14
5
0 Vdc, Common Alarm Low Relay Contact
15
6
Process Input (0-10 Vdc) Flow “OK” Relay Contact
16
7
Process Input (0- 0.5 Vac) 0 Vdc, Common
17
8
Servo Output (0-10 Vdc) Recorder Output (0-10 Vdc)
18
9
Enable Output (24 Vdc) 24 Vdc Power
19
10
0 Vdc, Common 0 Vdc, Common
20
