8. Schematics/Wiring Diagrams
PNEG-163-08 Centrifugal Fan 67
Motor Part # Capacitor Part # Capacitor Type MFD Voltage Qty
CF-3-1 Capacitor Specifications
C-7979
FH-7012 Electrolytic 161 250 1
FH-7000 Electrolytic 216 250 1
FH-7011 Oil 35 370 1
CHS-3-1 Capacitor Specifications
FH-5474 FH-7013 Electrolytic 850 115 1
CF-5-1 Capacitor Specifications
C-7980
FH-7000 Electrolytic 216 250 2
CH-6898 Oil 40 370 1
FH-5476
FH-7012 Electrolytic 216 250 2
CH-6898 Oil 40 370 1
FH-5478
FH-7000 Electrolytic 216 250 2
FH-7010 Oil 25 370 1
CF-7.5-1 Capacitor Specifications
C-7981
FH-7000 Electrolytic 216 250 2
CH-6898 Oil 40 370 1
CF-10-1 Capacitor Specifications
C-7982
FH-7000 Electrolytic 216 250 3
CH-6898 Oil 40 370 3
CHS-10-1 Capacitor Specifications
FH-5480
FH-7000 Electrolytic 216 250 3
CH-6897 Oil 30 370 2
CF-15-1 Capacitor Specifications
C-7982
FH-7000 Electrolytic 216 250 3
CH-6899 Oil 50 370 3
C-7983
FH-7000 Electrolytic 215 250 3
CH-6899 Oil 50 370 3
