4. Fan Specifications
PNEG-163-08 Centrifugal Fan
21
Discharge Bolt Pattern Dimensions
Figure 4B
1750 RPM Discharge Dimensions
3500 RPM Discharge Dimensions
NOTE: All dimensions in inches to nearest 1/32".
Fan
A
B
C
D
E
F
G
H
I
J
CF-3
1.531
4.688
5.906
5.906
7.094
1.094
0.875
2.406
7.844
***
CF-5
1.813
5.125
8.438
8.438
5.218
0.875
0.75
2.75
8.031
***
CF-7.5
1.813
5.125
8.438
8.438
5.218
0.875
0.75
3.75
9.906
***
CF-10
1.594
3.5
11.5
11.5
3.344
0.813
0.688
3.75
9.594
10.563
CF-15
1.594
3.5
11.5
11.5
3.344
0.813
0.688
5.75
10.313
11.281
CF-20
1.656
8.156
8.469
8.469
8.188
0.75
0.75
5.75
10.5
11.656
CF-25
1.656
8.156
8.469
8.469
8.188
0.75
0.75
5.75
11.656
12.813
CF-30
1.281
8.188
8.438
8.438
8.156
0.75
0.75
5.75
11.656
***
CF-40
1.281
8.188
8.438
8.438
8.156
0.75
0.75
5.75
12.563
***
CF-50
1.281
8.188
8.438
8.438
8.156
0.75
0.75
5.75
13.344
***
CF-30D - CF-50D
1.313
8.031
8.438
8.438
8.219
0.656
0.813
3.0 *
22.906
***
* 4 Holes @ 6" Spacing
Fan
A
B
C
D
E
F
G
H
I
J
CHS-3
1.625
4.313
4.125
4.125
4.063
1
0.781
2
5.125
***
CHS-5
1.625
4.313
4.125
4.125
4.063
1
0.781
2
6.094
***
CHS-7.5
1.625
3.531
4.75
4.75
6
1.094
0.875
2
6.094
***
CHS-10
1.625
3.531
4.75
4.75
6
1.094
0.875
2
6.094
***
CHS-15
1.625
3.531
4.75
4.75
6
1.094
0.875
2
6.094
***
CHS-20
1.531
4.688
5.906
5.906
7.094
1.094
0.875
2.406
7.375
***
CHS-30
1.531
4.688
5.906
5.906
7.094
1.094
0.875
2.781
8.125
***
CHS-40
1.531
4.688
5.906
5.906
7.094
1.094
0.875
3.063
9.344
***
CHS-50
1.813
5.125
8.438
8.438
5.219
0.875
0.75
3.063
8.781
***
