3. Fan/Heaters
PNEG-1934 Single Module Vision Hybrid Portable Dryer 79
Fan/Heater 36" 12 HP 230V 1 PH LP, VN2, CSA (3616V-2L-U) Parts List
Ref # Part # Description Qty
1 FHA-3615-VN2 Fan Housing Assembly, 36"-15 HP, VN2 1
2 FCP-BHL-LP Conduit Package, Burner High-Limit LP VN2 1
3 ADA-GENESIS Door Assembly, Burner Access, Vision Fan/Heaters 1
4 APA-36VN2 Adapter Plate Assembly 36" Vision N2 1
5 FDP-3612-2V Fan Drive Package, 36"-12 HP, 230V 3 PH, VN2 1
6 CD-FBA3610 PD Prop Assembly, 36"-10 HP, Composite 1
7 D04-0806 Burner Assembly, 36" PD Fan/Heater, VN2 1
8 S-7928 Flange Bolt 3/8"-16 x 1-1/2" YDP Grade 8 4
9 S-968 Flange Nut 3/8"-16 ZN Grade 5 4
10 TF-1558 Ignitor Assembly, Portable Dryer, 1/8" Gap 1
11 TF-1559-DT Flame Probe Assembly Dri-Tek and Dri-Tek Plus 1
12 FVH-12HP-2LG Fan Control Box 12 HP 208-230V 3P Hybrid Vision 1
13 D04-0934 Pipe Train Assembly, 36"-12 HP LP, VN2 1
14 D04-0933 Vaporizer Kit 1/2" NPT, 9" Coil, VN2 1
