1. Main Structure Assembly
26 PNEG-1934 Single Module Vision Hybrid Portable Dryer
7" Metering Rolls Parts List
Ref # Part # Description
1108 1112 1114 1116 1118 1120 1122 1126
D190 D270 D320 D370 D400 D460 D511 D601
Front
Metering
Roll
1 025-1217-6 Metering Roll Exterior 7' x 95.69" 2
1 025-1215-0 Metering Roll Exterior 7' x 71.313" 2 2 2
1 025-1216-8 Metering Roll Exterior 7' x 95.34" 2 2
1 025-1219-2 Metering Roll Exterior 7' x 119.41" 2 2
Middle
Metering
Roll
2 025-1218-4 Metering Roll Exterior 7' x 119" 2 2
Rear
Metering
Roll
3 025-1215-0 Metering Roll Exterior 7' x 71.313" 2 2
3 025-1216-8 Metering Roll Exterior 7' x 95.34" 2 2 2 2
3 025-1219-2 Metering Roll Exterior 7' x 119.41" 2
4 322-1033-8 Mach Bush 1" 18 Gauge 8 12 12 12 12 12 16 16
5 017-1542-4 Bearing - Phenolic 7" Metering Roll 2 2 2 2 2 4 4
6 093-1025-1 Clevis Pin 5/16" x 1-11/16" 8 16 16 16 16 16 24 24
7 S-6635 Cotter Pin 1/2" x 1" ZN 8 16 16 16 16 16 24 24
8 D31-0046 Metering Roll Splice Shaft 2 2 2 2 2 4 4
