3. Fan/Heaters
PNEG-1934 Single Module Vision Hybrid Portable Dryer 63
Flame Probe, Ignitor and Burner Assemblies
Figure 3I Conduit Package, Burner High-Limit LP VN2 (FCP-BHL-LP)
Conduit Package, Burner High-Limit LP VN2 (FCP-BHL-LP) Parts List
Ref # Part # Description Qty
1 D01-1473 Housing High-Limit Plate 1
2 027-1006-9 Thermostat, High-Limit 200°F AUTO 1
3 S-8472 Screw, TCSF #8-32 x 3/8" HWHS ZN 4
4 TFC-0076 Seal, Neoprene Conduit Body 1
5 THH-4064 Conduit, Unilet Type LRL Conduit box 1/2" 1
6 S-6550 Flat Washer #8 SAE ZN Grade S 2
7 S-280 Screw, SDS #10-16 x 5/8" HWH ZN 4
8 006-1360-4 Connector, 1/2" Elec Non-Metal 1
9 120-1538-4 Conduit, 1/2" Flexible Non-Metal 1
10 006-1371-0 Connector, 1/2" Elec Non-Metal 45° 1
11 FH-1310 Connector, Cord 1
