Page 10: Main structure assembly
1. Main Structure Assembly
10
PNEG-1934 Single Module Vision Hybrid Portable Dryer
Frame, Auger Trough, Hopper Bulkheads - 4" Metering Roll Parts List
The part number list above covers all parts pointed out on
,
and
Ref #
Part #
Description
Qty
1108
1112
1114
1116
1118
1120
1122
1126
D190
D270
D320
D370
D400
D460
D511
D601
1
D01-1136Y
Plenum Closure Door Angle, R.H.
3
5
6
7
8
9
10
12
2
D01-1136X
Plenum Closure Door Angle, L.H.
4
6
7
8
9
10
11
13
3
D01-0109
Hopper Bulkhead
6
10
12
14
16
18
20
24
4
D01-0004
Gusset Plate
10
14
16
18
20
22
24
28
5
D01-0005-BK
Side Leg Portable Dryer, Black
6
8
10
12
14
16
16
20
6
D01-0007-BK
Corner Leg Portable Dryer, Black
4
6
6
6
6
6
8
8
7
D01-0012-BK
Hitch Bracket - R.H. Black
1
1
1
1
1
1
1
1
8
D01-0011-BK
Hitch Bracket - L.H. Black
1
1
1
1
1
1
1
1
9
D01-0008-BK
Frame Tie Channel - Front, Rear and Center, Black
2
4
4
4
4
4
6
6
10
D01-2435
Front Bearing Plate 2008 4" Metering Rolls
1
1
1
1
1
1
1
1
11
D11-0005-BK
Frame Rail, 8' R.H. Black
1
D51-0002-BK
Frame Rail, 12' R.H. Black
1
D21-0011-BK
Frame Rail, 14' R.H. Black
1
D01-0538-BK
Frame Rail, 16' R.H. Black
1
D31-0044-BK
Frame Rail, 18' R.H. Black
1
D61-0002-BK
Frame Rail, 20' R.H. Black
1
D101-0002-BK
Frame Rail, 22' R.H. Black
1
D71-0001-BK
Frame Rail, 26' R.H. Black
1
11a
D11-0004-BK
Frame Rail, 8' R.H. Black
1
D51-0001-BK
Frame Rail, 12' L.H. Black
1
D21-0010-BK
Frame Rail, 14' L.H. Black
1
D01-0537-BK
Frame Rail, 16' L.H. Black
1
D31-0043-BK
Frame Rail, 18' L.H. Black
1
D61-0001-BK
Frame Rail, 20' L.H. Black
1
D101-0001-BK
Frame Rail, 22' L.H. Black
1
D71-0002-BK
Frame Rail, 26' L.H. Black
1
12
D01-0048
Trough Panel
8
12
14
16
18
20
22
26
13
D01-1512
Plate, Cross Channel Seal with Tabs
1
1
1
1
1
2
2
14
D01-1291
Hanger Bearing “C” Channel
1
1
1
1
1
2
2
15
D01-1290
Hanger Bearing “J” Plate
2
2
2
2
2
4
4
16
D02-0028
Clevis Pin 5/16" x 1-3/4"
16
24
32
32
40
40
48
56
17
D31-0148
Metering Roll Washer
8
12
16
16
20
20
24
28
18
D02-0061
Metering Roll Support Bearing
2
4
6
6
8
8
10
12
19
D01-0177
Support Strap
4
6
7
8
9
10
11
13
20
D01-1511
Plate, End Channel Seal with Tab
2
2
2
2
2
2
2
2
21
D01-2434
Discharge Plate 2008 4" Metering Roll
1
1
1
1
1
1
1
1
22
D31-0031
Metering Roll, Front
4
4
2
4
2
4
2
2
23
D31-0030
Metering Roll, Intermediate
2
4
4
6
6
8
10
24
D31-0029
Metering Roll, Rear
2
2
2
2
