2. Auger and Metering Roll Drive Trains
PNEG-1934 Single Module Vision Hybrid Portable Dryer 53
7" Bottom Auger Drive Parts List
Ref # Part # Description
Qty
1108 1112 1114 1116 1118 1120 1122 1126
D190 D270 D320 D370 D400 D460 D511 D601
1 D01-1949 Offset Plate Front Belt Guard 1 1 1 1 1 1 1 1
2
D02-0067 V-Belt BX85 2 2
MHC00490 V-Belt BX82 2 2 2 2 2 2
3
D03-0174 Sheave 2 Grade 3.35D x 1-1/8" Bore 1 1
2818-2 Sheave 2 Grade 3.35D x 1-1/8" Bore 1 1 1
D62-0003 Sheave 2 Grade 4.25D x 1-3/8" 1 1 1
4 D32-0019 Bushing Q1 - 1-1/2" Split Taper 1 1 1 1 1 1 1 1
5 D03-0304 Sheave 2GR 20" Grip Belt 1 1 1 1 1 1 1 1
6 D01-1848-6 Front Bearing Plate 1 1 1 1 1 1 1 1
7 D01-0017 Motor Adjustment Bracket 2 2 2 2 2 2 2 2
8 S-968 Flange Nut 3/8"-16 ZN Grade 5 6 6 6 6 6 6 6 6
9 S-6501 Bolt, HHTB 3/8"-16 x 4 ZN Grade 2 1 1 1 1 1 1 1 1
10 D01-0081 Motor Mount - Bottom Auger 1 1 1 1 1 1 1 1
11 D01-0016 Motor Mount Support Bracket 1 1 1 1 1 1 1 1
1 Phase 220 Volt
12 D03-1107
Motor, 2 HP 1 PH 1750 RPM 184T
TEFC GP
1 1
12 D03-1112
Motor, 3 HP 1 PH 1750 RPM 184T
TEFC GP
1
3 Phase 208/220/
440 Volt
12 MTR-0036 Motor 2 HP 3 PH 1800 RPM 1 1
12 MTR-0039 Motor 3 HP 3 PH 1800 RPM 1
12 MTR-0042 Motor 5 HP 3 PH 1800 RPM 1 1
12 MTR-0046 Motor 7.5 HP 3 PH 1800 RPM 1 1
12 MTR-0052 Motor 10 HP 3 PH 1800 RPM 1
