32
96827 v.6.0
If the Six-Gun Diesel Tuner has been
moved to a different vehicle, or you are
instructed to do so by Banks Technical
Staff, it is possible to reset all of the
parameters that the Six-Gun has ‘learned’
- presence of an EGT thermocouple or
Speed-Loader, etc.
CAUTION: The following procedures
can only be carried out with the
engine OFF!
1.
Turn the vehicle key to ON but DO
NOT start the engine.
2.
Fully depress the throttle pedal and
then release it completely. Repeat 5
times. The GREEN LED will flash when
this is completed successfully.
3.
Turn the key OFF. Wait 30 seconds, or
until the GREEN LED goes off and stays
off. Turn the key back to the ON position
but DO NOT start the engine.
4.
Fully depress the throttle pedal and
then release it completely. Repeat 5
times.
-END, SEcTION 7-
Section 7
CLEARING LEARNED INFORMATION
Section 8
REMOVAL OF THE SIX-GUN DIESEL TUNER
If the Six-Gun Diesel Tuner should ever
need to be removed from the vehicle,
perform the following:
NoTe: The ignition must remain in the
oFF position throughout the removal
process.
1.
Disconnect the Six-Gun’s PCM
connector from the left connection on
the PcM.
2.
Re-connect the vehicle’s PcM
connector back into the left connection
on the PcM.
3.
Disconnect the Six-Gun’s turbo
actuator connector from the vehicles
turbo actuator connection and harness.
Re-connect the vehicle’s turbo actuator
connector.
4.
Disconnect the 3 small connectors
on the ‘In-cab cable’ and gently pull the
cable back through the firewall.
5.
Remove the Six-Gun Diesel Tuner,
PcM harness and Turbo/In-cab harness
from the vehicle.
Failure to follow the above instructions
when removing the module will result in
a “check Engine” light on the dash and a
Diagnostic Trouble code being stored in
the factory computer, in addition to the
engine not running.
NoTe: Banks Brake will not function
without the Six-Gun Tuner installed.
-END, SEcTION 8-
Section 9
UPDATING BANKS IQ/POWERPDA & BANKS SIX-GUN/BRAKE
SOFTWARE
If a Tuner has been previously
installed, verify that the Tuner has
the latest version firmware. Check
your version to the current version
available on the Banks website.
SpeedBrake may not function
properly if Tuner/Brake firmware is
not up to the current version.
To update your PowerPDA go to
www.bankspower.com/downloads and
follow the updating instructions.
System Info
To view your System Information,
press the ‘System Info’ button in the
‘Adjustments’ menu (Refer to your
Banks iQ Owner’s Manual to open
the ‘Adjustment’ menu). See Figure
25. Use this info to verify that you
are downloading the correct update/
upgrade version for your Banks iQ. Press
the ‘Return ‘ icon to go back to the
‘Adjustment’ menu.
