96827 v.6.0
31
Code Event Course of Action
1, 1
Insufficient power
supply to brake
module
Turn Ignition OFF and check connection at fuse tap, 10-pin connection to
module and 8-pin connection to Tuner. Turn ignition back ON and re-check
for presence of code. If code does not re-appear at key ON, start engine
and check for presence of code both at engine idle and under varying
driving conditions.
1, 2
Brake signal
malfunction while
brake is on
Turn Ignition OFF and check connections at 5-pin male and female brake
pedal connector. Turn ignition back ON and re-check for presence of code.
If code does not re-appear at key ON, start engine and check for presence
of code both at engine idle and under varying driving conditions.
1, 3
Insufficient voltage to
tow-haul switch
Turn Ignition OFF and check connections at 3-pin male and female tow-
haul switch. Turn ignition back ON and re-check for presence of code. If
code does not re-appear at key ON, start engine and check for presence
of code both at engine idle and under varying driving conditions.
1, 4
Brake Signal
malfunction while
brake is off.
Turn Ignition OFF and check connections at 5-pin male and female brake
pedal connector. Turn ignition back ON and re-check for presence of code.
If code does not re-appear at key ON, start engine and check for presence
of code both at engine idle and under varying driving conditions.
2, 1
No response to
generated OBD ISO
messages
Turn Ignition OFF and check connections at OBD II connection. Turn
ignition back ON and re-check for presence of code. If code does not
re-appear at key ON, start engine and check for presence of code both at
engine idle and under varying driving conditions.
2, 2
Brake pressure switch
signal malfunction
Turn Ignition OFF and check connections at 2-pin male and female brake
pressure sensor intercept connector and 2-pin in-cab cable connector.
Turn ignition back ON and re-check for presence of code. If code does not
re-appear at key ON, start engine and check for presence of code both at
engine idle and under varying driving conditions.
3, 1
Rear wheel slip during
braking
Module has detected rear wheel slipping. code will automatically clear 30
seconds after traction regained.
3, 2
Power Up Error or
Internal Module
Malfunction
Turn Ignition OFF and check connection at fuse tap, 10-pin connection to
module and 8-pin connection to Tuner. Turn ignition back ON and re-check
for presence of code. If code does not re-appear at key ON, start engine
and check for presence of code both at engine idle and under varying
driving conditions.
3, 3
Internal Module
Malfunction
Turn Ignition OFF and check connection at fuse tap, 10-pin connection to
module and 8-pin connection to Tuner. Turn ignition back ON and re-check
for presence of code. If code does not re-appear at key ON, start engine and
check for presence of code both at engine idle and under varying driving
conditions.
4, 3
Exhaust Back Pressure
(EBP) Input Voltage Out
of Range
Turn Ignition OFF and check the 96-pin male and female PcM connectors.
Turn ignition back ON and re-check for presence of code. If code does not
re-appear at key ON, start engine and check for presence of code both at
engine idle and under varying driving conditions.
4, 4
communication failure
to brake module.
Turn Ignition OFF and check connections at 10-pin brake module, 8-pin Tuner,
and OBD II connector. Turn ignition back ON and re-check for presence
of code. If code does not re-appear at key ON, start engine and check for
presence of code both at engine idle and under varying driving conditions.
5, 1
Internal Module
Malfunction
Turn Ignition OFF and check connections at 10-pin brake module, 8-pin Tuner,
and OBD II connector. Turn ignition back ON and re-check for presence
of code. If code does not re-appear at key ON, start engine and check for
presence of code both at engine idle and under varying driving conditions.
Table 2: Banks Brake Fault Codes
