Rough Country 683X - Manual (Page 11)

23. Remove the rubber brake line from the steel line using a 12mm wrench as shown in Photo 12 and remove the brake
line from the caliper using a 15mm wrench.
24. Install the new brake line bracket using a 10mm wrench and stock hardware to secure to factory location. Install the
new brake line on the hard line and tighten. Install spring clip as shown in Photo 13. Install on the caliper with sup-
plied crush washers, using a 15mm wrench.
25. Reinstall the rear tires/wheels , using a 19mm deep well socket
26. Lower the vehicle to the floor.
27. Using a 21mm socket tighten the front and rear lower control arms, both ends to 130 ft.lbs.
28. Using a 18mm socket tighten the front upper control arms, both ends to 80 ft.lbs
29. Using a 21mm socket tighten the rear upper control arms to 130 ft. lbs.
30. Make sure the body is centered over the rear axle and install the rear track rod bracket in the factory location on the
frame with the factory hardware and using a 21mm wrench.
31. Adjust front draglink to center the steering wheel before driving by loosening the two bolts and turning the adjust-
ment collar. See PHOTO 14 & 15.
PHOTO 14 PHOTO 15
PHOTO 13 PHOTO 12
Remove the rear brake lines Install the new brake lines
Loosen adjustment collar Adjust as necessary
