Trektop NX Installation Instructions
Close
Zipper
Quarter Window
Close the zippers along the top of each Quarter
Window.
Close Upper Zipper on Quarter
Windows
Rear Window
Start Zipper
1-2"
Quarter
Window
Orient the Rear Window with the plastic J-slide
toward the top. Align the J-slide with the J-slide
sewn into the rear of the Top. Slide them together
until the Rear Window is centered in the opening.
Install Rear Window
Rear Window
J-Slide
Engage the Rear Window zipper with the Quarter
Panel zipper. Only close the zipper 1-2".
Engage Rear Window Zipper
Slip the plastic strip along the bottom of the Quarter
Windows into the channel in the belt rail on each
side of the vehicle.
Secure Quarter Windows to
Belt Rails
Quarter Window
Slip Plastic Strip
into Channel
Install Tailgate Bar
Slide the channel in the Tailgate Bar onto the tubing
along the bottom of the Rear Window on the inside.
Tailgate Bar
