Rough Country 736.20 - Manual (Page 3)

11. Loosen and remove lower control arms using a 22mm & 24mm wrench as shown in Photo 7 & 8. Retain the hard-
ware for reuse. Remove the lower control arms from the vehicle.
PHOTO 7 PHOTO 8
12. On the front cross-member, remove the 4 bolts securing the cross-member to the frame using a 17mm wrench as
shown in Photo 9. Retain hardware for reuse.
13. Remove the differential bolt as shown in Photo 10 using a 15mm wrench. Retain hardware for reuse. Remove the
factory cross-member and retain for reuse.
PHOTO 9 PHOTO 10
14. Remove driveshaft from the differential as shown in Photo 11 using a 13mm wrench. Retain hardware for reuse.
Secure driveshaft out of harms way.
PHOTO 12
15. Remove the two factory bump-stops from the frame using a 14mm wrench as shown in Photo 12 & 13.
16. Support the differential with a floor jack and remove the hardware on the drivers side as shown in Photo 14 using a
17mm wrench.
17. Retain the bump-stops / hardware for reuse.
PHOTO 13
PHOTO 14
PHOTO 11
