Rough Country 789.22 - Manual (Page 10)

56. Using two of the crossmember flag nuts and factory skid plate bolts attach the skid plate to the crossmember as
shown in Photo 40 & 41. Tighten with a 19mm socket.
57. Use stock hardware and a 19mm socket to bolt the skid plate to the gas tank mount. See Photo 42
58. Next if you are installing on a 4-door use the skid plate mount as shown in Photo 43. Use the supplied 9/16” x 1 1/2”
bolt, washers, and nut and the supplied 1/2” x 1 1/2” long bolt, washers, and nut to bolt the mount to the skid plate.
Tighten the 9/16” bolt with a 21mm socket and 22mm wrench and tighten the 1/2” bolt with a 19mm socket. Next use
factory hardware to bolt the mount to the frame. Tighten with a 18mm socket.
59. If installing on a 2-door the outside hole of the skid plate will bolt to the rear lower control arm bracket bolt.
60. Reinstall the front tires/wheels using a 19mm deep well socket.
61. Lower the vehicle to the floor and proceed to the rear installation.
PHOTO 43
PHOTO 40
PHOTO 42
PHOTO 41
