Rough Country 1117 User Manual
Page 3
15. Tighten 1/2 inch hardware with 19mm or 3/4” socket / wrench.
16. Install the shackle with the supplied 14mm x 110mm bolt, washer and lock nut. See Photo 7. Do not tighten at this
time.
17. Install spring into shackle using supplied 14mm x 110mm Bolt, washers and lock nut. See Photo 8. Do not tighten at
this time.
18. Reinstall wheels / tires
19. Remove jack stands
20. Place vehicle on ground.
21. Torque shackle and spring bolts to factory specifications using a 22mm socket / wrench.
PHOTO 7
PHOTO 8
REINSTALL SHACKLE
REINSTALL LEAF SPRING
Front 1 1/2” Spacers Available….Part # 7594
