41. Install the stock brake line bracket onto the knuckle as shown in
Photo 31 using the stock hardware. Tighten using
12mm wrench.
42. Install the ABS sensor into the knuckle using a 5mm allen wrench and install the factory bracket back onto the upper
a-arm using a 10mm wrench and stock bolt .
It may be necessary to slightly pull the ABS wire to create slack .
WD-40 can be used to lube the line to allow it to slide in the upper control arm mount. Reinstall the ABS
bracket on the knuckle as shown using the stock hardware. Tighten using a 12mm wrench.
See Photo 32.
43. Install the tie-rod end into the knuckle using a 24mm wrench to tighten in
Photo 33. Make sure the cotter key is
installed. Tighten the jam nut on the tie-rod end using a 1 1/16 ” and a 1 3/16” wrench.
44. Install skid plate as shown in
Photo 34 using the previously installed 9/16” rear diff. bracket bolts and supplied 3/8” x
1 ” bolts and nuts and 2 washers. (4WD Model) Use a 9/16” wrench for the front bolts and a 21mm for the rear diff
bolts that secure the skid plate.
45. Install the wheels and tires. Jack up the front of the vehicle and remove the jack stands. Lower the vehicle to the
ground and tighten lower control arm bolts using a 21mm wrench.
Photo 31 Photo 32
Photo 33 Photo 34
