16. Remove the lower strut bolt using a 30mm socket and 1 –1/16” wrench. See Photo 13. Retain hardware for reuse.
17. Remove the sway bar from the frame mount using a 15mm socket. Please note the position that the sway bar is in-
stalled from the factory to make sure it is reinstalled correctly. Retain hardware for reuse. See Photo 14.
18. Remove the lower control arm using a 21mm and 1-1/16” wrench. Retain hardware for reuse. See Photo 15.
19. Remove the strut from the upper mount using a 15mm socket / wrench. Retain hardware for reuse. See Photo 16.
20. Remove the lower skid plate by removing the 4 bolts using a 13mm socket. See Photo 17.
21. Remove the driveshaft from the front differential using a 10mm socket. See Photo 18. Secure driveshaft out of the
way.
PHOTO 13 PHOTO 14
REMOVE THE LOWER STRUT BOLT REMOVE THE SWAY BAR FROM FRAME
PHOTO 15 PHOTO 16
PHOTO 17 PHOTO 18
REMOVE THE LOWER CONTROL ARM REMOVE THE UPPER STRUT HARDWARE
REMOVE THE LOWER SKID PLATE REMOVE THE DRIVE SHAFT
