Rough Country 598S User Manual
Page 4
9. Remove the dust shield using a 8mm socket and dust cap. See Photo 7.
10. Remove the ABS wire from the bearing assembly using a 5mm allen wrench. See Photo 8.
11. Remove the axle nut using a 13mm socket. Retain hardware for reuse. See Photo 9.
12. Loosen the upper ball joint nut using a 21mm wrench. Tap lightly with a hammer to release ball joint from knuckle.
See Photo 10.
13. Loosen the lower ball joint using a 24mm wrench. Tap lightly with a hammer to release ball joint from knuckle. See
Photo 11.
14. Remove the upper and lower ball joint nuts and remove the knuckle from the vehicle.
15. Remove the sway bar links from the sway bar using a 19mm wrench. Retain hardware for reuse. See Photo 12.
PHOTO 7
REMOVE THE DUST SHIELD
PHOTO 8
REMOVE THE ABS WIRE
PHOTO 9
PHOTO 10
PHOTO 11
PHOTO 12
REMOVE THE AXLE NUT
TAP TO LOOSEN UPPER BALL JOINT
TAP TO LOOSEN LOWER BALL JOINT
REMOVE UPPER SWAY BAR HARDWARE
